View transitions

Morph is on by default (viewTransition on Root). Pass viewTransition={false} to opt out. Recommended destination shape: Lightbox.Media around the <img> / <video> (sized fit-box = morph target + placeholder host). On Trigger, prefer a render prop:

• imageRef — put on the Trigger thumb <img> whose pixels bridge the morph. Media auto-discovers the destination image (or video poster). Lets open reuse an already-decoded bitmap so the transition doesn’t flash empty space.
• morphRef — optional escape hatch when morph bounds should differ from Media / the image (tile with overlay, swatch + label).

Nested wrappers can use useLightboxTriggerContext / useLightboxItemContext instead of threading the render prop. Use awaitImageDecode on Root when you want a short wait for the destination image before the morph starts (default ~200ms cap).

import * as Lightbox from '@ramka/react/lightbox';

<Lightbox.Root morphTo="active">
  <Lightbox.Trigger index={0}>{({ imageRef }) => <img ref={imageRef} src={thumb} alt="" />}</Lightbox.Trigger>

  <Lightbox.Portal>
    <Lightbox.Backdrop />
    <Lightbox.Content>
      <Lightbox.Slides>
        <Lightbox.Slide>
          <Lightbox.Item index={0}>
            <Lightbox.Zoom>
              <Lightbox.Media>
                <img src={src} alt="" />
              </Lightbox.Media>
            </Lightbox.Zoom>
          </Lightbox.Item>
        </Lightbox.Slide>
      </Lightbox.Slides>
    </Lightbox.Content>
  </Lightbox.Portal>
</Lightbox.Root>

The morph snapshots whatever pixels are on the trigger <img> and interpolates them into the destination Media box. That only looks like one photo when both sides share the same intrinsic aspect ratio — the same file, or srcset candidates of that file. A square tile is fine; crop it with CSS (object-fit: cover), not by baking w=h&fit=crop into a different image.

A CDN-cropped 1∶1 thumb against a 3∶2 lightbox image will reframe mid-animation: Ramka paints the square thumb into the landscape box, then the full file lands with a different crop. Element boxes may differ. Intrinsic aspect must not.

These demos delay the lightbox image by ~500ms so the handoff is visible on every open.

Do

Do — same source aspectCopy

import * as Lightbox from '@ramka/react/lightbox';

<Lightbox.Root>
  <Lightbox.Trigger index={0}>
    {({ imageRef }) => (
      <Image
        ref={imageRef}
        src={photo}
        alt="Photo"
        placeholder="blur"
        className="aspect-square size-full object-cover"
      />
    )}
  </Lightbox.Trigger>

  <Lightbox.Portal>
    <Lightbox.Backdrop />
    <Lightbox.Content>
      <Lightbox.Slides>
        <Lightbox.Slide>
          <Lightbox.Item index={0}>
            <Lightbox.Zoom>
              <Lightbox.Media width={photo.width} height={photo.height}>
                <Image src={photo} alt="Photo" sizes="100vw" priority />
              </Lightbox.Media>
            </Lightbox.Zoom>
          </Lightbox.Item>
        </Lightbox.Slide>
      </Lightbox.Slides>
    </Lightbox.Content>
  </Lightbox.Portal>
</Lightbox.Root>

Don’t

Don’t — baked square cropCopy

import * as Lightbox from '@ramka/react/lightbox';

<Lightbox.Root>
  <Lightbox.Trigger index={0}>
    {({ imageRef }) => (
      // ❌ 1∶1 file. Media below is the full 3∶2 photo.
      <Image ref={imageRef} src={squareThumb} alt="Photo" className="size-full object-cover" />
    )}
  </Lightbox.Trigger>

  <Lightbox.Portal>
    <Lightbox.Backdrop />
    <Lightbox.Content>
      <Lightbox.Slides>
        <Lightbox.Slide>
          <Lightbox.Item index={0}>
            <Lightbox.Zoom>
              <Lightbox.Media width={photo.width} height={photo.height}>
                <Image src={photo} alt="Photo" sizes="100vw" priority />
              </Lightbox.Media>
            </Lightbox.Zoom>
          </Lightbox.Item>
        </Lightbox.Slide>
      </Lightbox.Slides>
    </Lightbox.Content>
  </Lightbox.Portal>
</Lightbox.Root>

Controls whether the morph dissolves between trigger and item snapshots or hard-cuts geometry only.

• Omit (default) — hard-cut. Best when trigger and item show the same picture at the same intrinsic aspect (a CSS object-cover window or a smaller srcset is fine; a CDN-baked crop that changes the aspect is not — see Source aspect). Leaves data-ramka-crossfade unset on <html> during the transition.
• both — dissolve on open and close (stack → single photo, +N overlay tile, etc.).
• open / close — dissolve in one direction only (e.g. poster → live video often wants close).

Keep trigger and item images on object-fit: cover (or the same fit) so crops stay coherent. Put border-radius on the morph target itself — the library interpolates --lightbox-morph-border-radius-from/to on <html>.

Value	Use when
undefined	Same picture, same intrinsic aspect ratio — element boxes may differ
"both"	Trigger ≠ item both ways — stacks, +N overlays, swatches
"close"	Open frames match, close doesn't — poster → playing video
"open"	Rare inverse of close

Omit — same picture

Same picture and intrinsic aspect ratio; element boxes may differ. Both sides use object-fit: cover. Below: square thumbs → landscape viewer from 3∶2 sources.

crossfade="both" — +N tile

Open dissolves the overlay/+N tile into a clean photo. Close from a photo without a thumb uses morphTo="closest".

+5

crossfade="both" — any element

Morph sources don't have to be images — dissolve initials chips into portraits so letters don't stretch.

• AC
  Ava Chen
• JO
  Jules Okonkwo
• SR
  Sam Rivera
• ML
  Mei Laurent

crossfade="close" — poster → video

Open hard-cuts into the matching poster frame; close dissolves the live video back to the poster.

crossfade="both"Copy

import * as Lightbox from '@ramka/react/lightbox';

<Lightbox.Root morphTo="closest">
  <Lightbox.Trigger index={0} crossfade="both">
    {({ imageRef }) => (
      <div className="relative">
        <Image ref={imageRef} src={photo} alt="" placeholder="blur" />
        <span>+{extras}</span>
      </div>
    )}
  </Lightbox.Trigger>
  <Lightbox.Portal>
    <Lightbox.Backdrop />
    <Lightbox.Content>
      <Lightbox.Slides>
        <Lightbox.Slide>
          <Lightbox.Item index={0}>
            {({ imageRef }) => <Image ref={imageRef} src={photo} alt="" sizes="100vw" priority />}
          </Lightbox.Item>
        </Lightbox.Slide>
      </Lightbox.Slides>
    </Lightbox.Content>
  </Lightbox.Portal>
</Lightbox.Root>

Picks which trigger receives the close morph:

• active (default) — trigger for the current active index. No morph if that index has no trigger.
• origin — always the trigger that opened the lightbox (one tile opens many items).
• closest — active index if registered, otherwise the nearest registered trigger.

morphTo="active"

Default. Close morphs to the trigger matching the active index. All five images have triggers.

morphTo="origin"

Always morph back to the trigger that opened the lightbox (one tile, many items).

morphTo="closest"

Active trigger if registered, otherwise the nearest one — useful for +N grids (only first 3 have triggers below).

morphTo="closest"Copy

import * as Lightbox from '@ramka/react/lightbox';

<Lightbox.Root morphTo="closest">
  <Lightbox.Trigger index={0}>{/* first thumb */}</Lightbox.Trigger>
  <Lightbox.Trigger index={1}>{/* +N tile */}</Lightbox.Trigger>
  {/* items 2…n close to the nearest trigger */}
  <Lightbox.Portal>
    <Lightbox.Backdrop />
    <Lightbox.Content>
      <Lightbox.Slides>
        <Lightbox.Slide>
          <Lightbox.Item index={0} />
        </Lightbox.Slide>
        <Lightbox.Slide>
          <Lightbox.Item index={1} />
        </Lightbox.Slide>
        <Lightbox.Slide>
          <Lightbox.Item index={2} />
        </Lightbox.Slide>
      </Lightbox.Slides>
    </Lightbox.Content>
  </Lightbox.Portal>
</Lightbox.Root>

When the page scrolls while the lightbox is open, the close morph can land off-screen. Use scrollTriggerIntoView to keep the target trigger in view:

• onChange — scroll to the active trigger as the index changes (preemptive).
• onOpenComplete — reposition once open settles (invisible under the overlay; instant recommended).
• onClose — scroll just before the close morph (visible jump at close start).

Pass one option or an array. Each option also accepts block / inline alignment (defaults nearest) — use inline: 'center' for horizontal snap strips with variable-width tiles. Pair with morphTo so the scrolled element is the same one that receives the morph.

import * as Lightbox from '@ramka/react/lightbox';

<Lightbox.Root
  scrollTriggerIntoView={[
    { type: 'onChange', behavior: 'instant' },
    { type: 'onOpenComplete', behavior: 'instant' },
  ]}
>
  {/* triggers + content */}
</Lightbox.Root>

Prefer createHandle(): open(index, { triggerId }) associates a Trigger that declared that id so the open morph can use that element. Without a registered trigger (or triggerId), the open falls back to the fade path. Trigger clicks still morph. Demo: State & lifecycle → Imperative API.

You write zero view-transition CSS: the library injects the structural ::view-transition-* rules itself (see Injected CSS) and writes document hooks during a morph so your own skin CSS can react — e.g. keep Backdrop/Content fades on the morph's clock. Attribute / CSS-variable tables live under Document (view transitions). Hooks:

• data-ramka-view-transition — opening | closing
• data-ramka-crossfade — dissolve path (present when Triggercrossfade is active for this phase; absent for hard-cut)
• --lightbox-morph-border-radius-from/to, --lightbox-morph-old/new-opacity
• data-ramka-vt-preset, --lightbox-vt-duration, --lightbox-vt-easing, --lightbox-vt-crossfade-close-easing, --lightbox-vt-root-easing — the active timing preset, written by the library (see Timing presets)
• Trigger data-morph-target / Item data-skip-fade — hide the live morph source and suppress entrance fades on the destination while the VT layer is up

Motion splits into timing (a preset picked on Root — see below) and structure (injected by the library). Your CSS only handles cosmetics — and reads the library-written contract vars where it wants to stay in sync.

Morph duration and easing are chosen with the viewTransition prop on Root — pass a preset name instead of true:

• "default" — 360ms, sheet curve with a tamed launch (what true runs)
• "snappy" — 340ms, hotter launch; reads quicker
• "relaxed" — 400ms, softer launch and longer settle
• "spring" — 450ms, critically damped spring; Photos-style settle

<Lightbox.Root viewTransition="spring">{/* … */}</Lightbox.Root>

Timing is preset-based rather than free-form CSS on purpose: each preset is vetted on-device to stay smooth and skip-safe on iOS Safari (including Low Power Mode) and Android, where arbitrary curves stutter or teleport. The library publishes the preset timing as --lightbox-vt-duration / --lightbox-vt-easing / --lightbox-vt-root-easing in two places: always on the Portal host, and — together with data-ramka-vt-preset — on documentElement for the duration of a morph. Read those vars in your own CSS as the skin's single motion clock (e.g. transition: opacity var(--lightbox-vt-duration, 360ms) ease-out on Backdrop/Content): during a morph the fades stay in lockstep with it, and on the non-morph paths (unsupported browsers, reduced motion, low-end fallback) they still run on the preset's timing; do not set the vars yourself.

On first Root mount the library injects one stylesheet with everything a morph structurally needs — no copy-paste block to maintain, and multiple skins on one page can never fight over it:

• Name isolation — startViewTransition snapshots the whole document, so any page element with its own view-transition-name would paint over the lightbox. Every name is cleared while data-ramka-view-transition is set; the morph target re-applies its name inline with !important and stays the only captured group.
• Morph group — clipping + border-radius interpolation (put radius on the morph target element; JS writes --lightbox-morph-border-radius-from/to), timed by the active preset.
• Snapshots — hard-cut by default (object-fit: cover, no UA dissolve); when Trigger crossfade sets data-ramka-crossfade, the dissolve path (UA fade, plus-lighter, object-fit: fill) runs on the same preset clock. Open uses the morph ease-out so the destination appears promptly; both phases run that complementary dissolve on a shorter window so the outgoing snapshot is gone before the size settle (`plus-lighter` stays opaque).
• Root snapshot — the page-behind crossfade, kept as a single root group (promoting Backdrop / Content into named groups tanks Safari). Fade scrim and chrome with live opacity transitions instead.
• Morph-target hide — [data-morph-target] gets opacity: 0 with a 200ms fade-back (disabled during the transition so it can't be captured mid-flight), so the live trigger never shows doubled under the morphing snapshot.
• Thumb-jump crossfade — the element-scoped Slides transition started by ThumbnailStrip's selectViewTransition, tunable via --lightbox-select-vt-duration/easing on Slides.

Everything except name isolation is gated under prefers-reduced-motion: no-preference. The stylesheet is inserted at the start of <head>, so your own stylesheets cascade after it — overriding any injected rule takes an ordinary declaration of equal specificity, no !important needed.

Lifecycle timing for your own CSS: Content/Backdrop stay mounted through exit animations; while a VT open is preparing they may be visibility: hidden so the morph layer owns the pixels. Prefer onOpenChangeComplete for post-motion work — see State & lifecycle → Lifecycle callbacks.
